Precision Roll-to-Roll Metal Etching Services for High-Volume Orders
Roll-to-Roll Overview
Xinhaisen Technology specializes in high-precision roll-to-roll etching services, offering continuous, high-volume production of precision metal etched components. This process is ideal for manufacturing large quantities of intricate parts with consistent quality and exceptional efficiency. Our roll-to-roll etching capabilities ensure superior accuracy, flexibility, and cost-effectiveness for projects requiring complex designs and tight tolerances.
Roll-to-Roll Key Feature
Extreme Precision: Micro holes down to 0.03mm, fine lines to 0.015mm.
High Speed & Volume: Perfect for large orders with fast turnaround.
Excellent Consistency: Etch uniformity within ±0.03mm.
Wide Material Range: Stainless steel, copper, brass, aluminum, nickel, and more.
No Burrs, No Stress: Chemical process ensures clean, flat parts with no mechanical damage.
Flexible Orders: From prototypes to super-sized production runs.
Roll-to-Roll Specification
| Parameter | Capability |
| Material Thickness | 0.02mm – 1.5mm |
| Min. Hole Size | 0.03mm |
| Min. Line Width | 0.015mm |
| Etching Uniformity | ±0.03mm |
| Common Materials | Stainless Steel, Cu, Brass, Al, Ni, Alloys |
Our Services
Prototype development and small-batch production.
Large-volume manufacturing with fast turnaround.
Custom material selection and design optimization.
Strict quality control and full compliance with industry standards.
End-to-end support from design to delivery.
Contact Us Today!
Ready to start your project? Contact Xinhaisen for experienced roll-to-roll etching solutions that combine precision, speed, and scale. Let’s work together to bring your designs to life—efficiently and reliably.
